Shower hose
ITEM:Anti Twist
CODE:GGH012-12A04
APPLICATION:Suitable for connecting shower head and waterheater,faucet and shower room.
Name:Shower hose
Product:
E-mai
Content:


TYPE 1
DESCRIPTION: 360° ANTI-TWIST SHOWER HOSE, EPDM INNER PIPE

NO.FITTINGITEMSIZEMATERIALQTY
1NUTConical F1/223x30x15.5BRASS(58-3A), Cr-plated1
2NUT B-1Hexagonal F1/223x13x15.5BRASS(58-3A), Cr-plated1
3NIPPLE 13x26x9NYLON1
4INSERT SET(O-ring)F1/2 BRASS(58-3A)1
6INSERTF1/28.2x17BRASS(58-3A)1
7WASHERF1/218x11x3EPDM2
8SLLEVE--14.8x0.3x19S.S.304, Cr-plated2
9INNER PIPE--6x8EPDM1
10BAND--Thickness 0.20S.S.3041
11OUTER PIPE--13.8S.S.304, Cr-plated, Double Lock1
TECHNICAL DATA
Length   20cm - 225cm
Pull   50 Kg
Working Pressure  10 Bar
Burst Pressure  35 Bar
Working Temperature 1-90 ℃

TYPE 2
 DESCRIPTION: 360° ANTI-TWIST SHOWER HOSE, EPDM INNER PIPE

NO.FITTINGITEMSIZEMATERIALQTY
1NUTConical F1/222.8x28x15.5BRASS(58-3A), Cr-plated1
2NUT B-1Hexagonal F1/222.8x12.5x15.5BRASS(58-3A), Cr-plated1
3NIPPLE 13x26x9NYLON1
4INSERT SET(O-ring)F1/2 BRASS(58-3A)1
6INSERTF1/28.2x14BRASS(58-3A)1
7WASHERF1/218x11x3EPDM2
8SLLEVE--14.8x0.3x19S.S.201, Cr-plated2
9INNER PIPE--6x8EPDM1
10BAND--Thickness 0.16S.S.2011
11OUTER PIPE--13.8S.S.201, Cr-plated, Double Lock1
TECHNICAL DATA
Length   20cm - 225cm
Pull   50 Kg
Working Pressure  10 Bar
Burst Pressure  35 Bar
Working Temperature 1-90 ℃


TYPE 3
DESCRIPTION: 360° ANTI-TWIST SHOWER HOSE, EPDM INNER PIPE

NO.FITTINGITEMSIZEMATERIALQTY
1NUTConical F1/222.8x28x15.5BRASS(58-3A), Cr-plated1
2NUT B-1Hexagonal F1/222.8x12.5x15.5BRASS(58-3A), Cr-plated1
3NIPPLE 13x26x9NYLON1
4INSERT SET(O-ring)F1/2 BRASS(58-3A)1
6INSERTF1/28.2x14BRASS(58-3A)1
7WASHERF1/218x11x3EPDM2
8SLLEVE--14.8x0.3x19S.S.201, Cr-plated2
9INNER PIPE--6x8PVC1
10BAND--Thickness 0.16S.S.2011
11OUTER PIPE--13.8S.S.201, Cr-plated, Double Lock1
TECHNICAL DATA
Length   20cm - 225cm
Pull   50 Kg
Working Pressure  10 Bar
Burst Pressure  35 Bar
Working Temperature 1-65 ℃
