TYPE 1
DESCRIPTION: PULL-OUT SHOWER HOSE, EPDM INNER PIPE
| NO. | FITTING | ITEM | SIZE | MATERIAL | QTY | |||
| 1 | NUT A-6 | Conical F1/2 | 23x30x15.5 | BRASS(58-3A), Cr-plated | 1 | |||
| 2 | NUT B-1 | Hexagonal F1/2 | 23x13x15.5 | BRASS(58-3A), Cr-plated | 1 | |||
| 3 | INSERT 1 | F1/2 | 6.4x20 | BRASS(58-3A) | 2 | |||
| 6 | WASHER | F1/2 | 18x11x3 | EPDM | 2 | |||
| 7 | SLLEVE INNER | -- | S.S.304, Cr-plated | 2 | ||||
| 8 | SLLEVE OUTER | -- | 14.8x0.3x19 | S.S.304, Cr-plated | 2 | |||
| 9 | INNER PIPE | -- | 6x8 | EPDM | 1 | |||
| 10 | WIRE | -- | 0.20mm | NYLON (black) | 1 | |||
| 11 | BAND | -- | Thickness 0.20 | S.S.304 | 1 | |||
| 12 | OUTER PIPE | -- | 13.8 | S.S.304, Cr-plated, Double Lock | 1 | |||
| TECHNICAL DATA | ||||||||
| Length | 20cm - 225cm | |||||||
| Pull | 50 Kg | |||||||
| Working Pressure | 16 Bar | |||||||
| Burst Pressure | 80 Bar | |||||||
| Working Temperature | 1-90 ℃ | |||||||
TYPE 2
DESCRIPTION: PULL-OUT SHOWER HOSE, EPDM INNER PIPE
| NO. | FITTING | ITEM | SIZE | MATERIAL | QTY | |||
| 1 | NUT A-6 | Conical F1/2 | 23x30x15.5 | BRASS(58-3A), Cr-plated | 1 | |||
| 2 | NUT B-1 | Hexagonal F1/2 | 23x13x15.5 | BRASS(58-3A), Cr-plated | 1 | |||
| 3 | INSERT 1 | F1/2 | 6.4x20 | BRASS(58-3A) | 2 | |||
| 6 | WASHER | F1/2 | 18x11x3 | EPDM | 2 | |||
| 7 | SLLEVE INNER | -- | S.S.201, Cr-plated | 2 | ||||
| 8 | SLLEVE OUTER | -- | 14.8x0.3x19 | S.S.201, Cr-plated | 2 | |||
| 9 | INNER PIPE | -- | 6x8 | EPDM | 1 | |||
| 10 | WIRE | -- | 0.20mm | NYLON (black) | 1 | |||
| 11 | BAND | -- | Thickness 0.20 | S.S.201 | 1 | |||
| 12 | OUTER PIPE | -- | 13.8 | S.S.201, Cr-plated, Double Lock | 1 | |||
| TECHNICAL DATA | ||||||||
| Length | 20cm - 225cm | |||||||
| Pull | 50 Kg | |||||||
| Working Pressure | 16 Bar | |||||||
| Burst Pressure | 80 Bar | |||||||
| Working Temperature | 1-90 ℃ | |||||||
