Shower hose
ITEM:Anti Twist+Pull out
CODE:GGH012-12A10
APPLICATION:Suitable for connecting shower head and waterheater,faucet and shower room.
Name:Shower hose
Product:
E-mai
Content:


TYPE 1
 DESCRIPTION: 360° ANTI-TWIST, PULL-OUT SHOWER HOSE, EPDM INNER PIPE

NO.FITTINGITEMSIZEMATERIALQTY
1NUT A-9Conical F1/223x30x15.5BRASS(58-3A), Cr-plated1
2NUT B-1Hexagonal F1/223x13x15.5BRASS(58-3A), Cr-plated1
3INSERT 1F1/26.4x29.2BRASS(58-3A)2
4INSERT 2F1/26.4x12.5BRASS(58-3A)2
5INSERTF1/26.4x20BRASS(58-3A)2
6WASHERF1/218x11x3EPDM2
7SLLEVE INNER-- S.S.304, Cr-plated2
8SLLEVE OUTER--14.8x0.3x19S.S.304, Cr-plated2
9INNER PIPE--6x8EPDM1
10WIRE--0.20mmNYLON (black)1
11BAND--Thickness 0.20S.S.3041
12OUTER PIPE--13.8S.S.304, Cr-plated, Double Lock1
TECHNICAL DATA
Length   20cm - 225cm
Pull   50 Kg
Working Pressure  10 Bar
Burst Pressure  80 Bar
Working Temperature 1-90 ℃






 TYPE 2
 DESCRIPTION: 360° ANTI-TWIST, PULL-OUT SHOWER HOSE, EPDM INNER PIPE

NO.FITTINGITEMSIZEMATERIALQTY
1NUT A-9Conical F1/222.8x30x15.5BRASS(58-3A), Cr-plated1
2NUT B-1Hexagonal F1/222.8x13x15.5BRASS(58-3A), Cr-plated1
3INSERT 1F1/26.4x29.2BRASS(58-3A)2
4INSERT 2F1/26.4x12.5BRASS(58-3A)2
5INSERTF1/26.4x19BRASS(58-3A)2
6WASHERF1/218x11x3EPDM2
7SLLEVE INNER-- S.S.201, Cr-plated2
8SLLEVE OUTER--14.8x0.3x19S.S.201, Cr-plated2
9INNER PIPE--6x8EPDM1
10WIRE--0.20mmNYLON (black)1
11BAND--Thickness 0.16S.S.2011
12OUTER PIPE--13.8S.S.201, Cr-plated, Double Lock1
TECHNICAL DATA
Length   20cm - 225cm
Pull   50 Kg
Working Pressure  10 Bar
Burst Pressure  80 Bar
Working Temperature 1-90 ℃
