Shower hose
ITEM:Spring Shower Hose
CODE:GGH012-12A15
APPLICATION:Suitable for connecting shower head and waterheater,faucet and shower room.
Name:Shower hose
Product:
E-mai
Content:


TYPE 1
 DESCRIPTION: SPRING SHOWER HOSE

NO.FITTINGITEMSIZEMATERIALQTY
1NUTConical F1/223x30x15.5BRASS(58-3A), Cr-plated1
2NUTRound F1/223x13x15.5BRASS(58-3A), Cr-plated1
3INSERT 9.5X17BRASS(58-3A)2
4WASHERF1/218x11x3EPDM2
5DOUBLE SLLEVE--14.8x0.3x19S.S.201, Cr-plated2
6INNER PIPE--7x9EPDM1
7OUTER PIPE--13.2STAINLESS STEEL, Cr-plated2
TECHNICAL DATA
Length   20cm - 225cm
Pull   5 Kg
Working Pressure  8 Bar
Burst Pressure  15 Bar
Working Temperature 1-90 ℃


 TYPE 2
 DESCRIPTION: SPRING SHOWER HOSE

NO.FITTINGITEMSIZEMATERIALQTY
1NUTConical F1/223x30x15.5BRASS(58-3A), Cr-plated1
2NUTRound F1/223x13x15.5BRASS(58-3A), Cr-plated1
3INSERT 9.5X17BRASS(58-3A)2
4WASHERF1/218x11x3EPDM2
5DOUBLE SLLEVE--14.8x0.3x19S.S.2012
6INNER PIPE--7x9EPDM1
7OUTER PIPE--13.2STAINLESS STEEL2
TECHNICAL DATA
Length   20cm - 225cm
Pull   5 Kg
Working Pressure  8 Bar
Burst Pressure  15 Bar
Working Temperature 1-90 ℃
